DC-DC Converter 48-12V

SKU: 9010200006012 Categories: , , , ,

25.23

TW-DCC1201 DC converter 36/75V-12V

10 in stock

Description

Townet dc-dc converter

operate over an input voltage range between 36 Vdc to 75 Vdc and provide a precisely regulated DC output, with a maximum power rating of 75W (usually the power consumption of a base station or cpe is between 5 and 8W), and a full load efficiency of 85%.
The insulation between case and output permit to serialize the output of two dc-dc converters to obtain 24 volts.

– Input: 36-75V DC
– Output: 12V DC
– Power: 75W
– Low noise
– Small size
– High power density 75W
– High efficiency over 85%
– Weight of only 120g
– Constant frequency
– Metal baseplate with screw holes to fix it.
– Case ground pin, insulation of output.
– Overcurrent, overvoltage protection, input fuse.
– CMRR filter for input noise

Download DC-DC converter datasheet.pdf

Additional information

Weight 0.1500 kg
Brand

Townet
