DISC Lite5

Sku:1010190100500

MikroTik - RBDisc-5nD - DISC Lite5 - Dual chain 21dBi 5GHz CPE/Point-to-Point Integrated Antenna, 600Mhz CPU, 64MB RAM
37,36 €

Availability: In stock

  • Buy 5 for 37,21 € each and save 1%
  • Buy 10 for 36,89 € each and save 2%
  • Buy 20 for 36,73 € each and save 2%

DISC Lite5 is an integrated 21dBi Dual Chain 802.11n CPE with a 600MHz CPU, 64MB RAM, 1x 10/100Mbps Ethernet port and RouterOS L3 installed. The DISC uses a backfire type antenna which allows to reach 21dBi gain in such a low cost and compact package.

The device comes complete with a power supply, PoE injector and mounting kit for a ultra low cost at $48!

The RouterOS Level3 allows to use the DISC Lite5 as CPE or Point-to-Point 5GHz links.

We have one version available.

- DISC Lite5 (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).



Specifications

Details
Product code RBDisc-5nD
Architecture MIPSBE
CPU AR9344
CPU core count 1
CPU nominal frequency 600 MHz
Dimensions ⌀ 265mm, height: 80mm
License level 3
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C to 70°C
Suggested price $48.00


Powering

Details
PoE in Passive PoE
PoE in input Voltage 10-30 V
Number of DC inputs 1 (PoE-IN)
Max power consumption 6 W


Wireless

Details
Wireless 5 GHz number of chains 2
Wireless 5 GHz Max data rate 300 Mbit/s
Wireless 5 GHz standards 802.11a/n
Antenna gain dBi for 5 GHz 21
Wireless 5 GHz chip model AR9344


Ethernet

Details
10/100 Ethernet ports 1


Wireless specifications

5 GHzTransmit (dBm)Receive Sensitivity
6MBit/s 25 -96
54MBit/s 20 -80
MCS0 25 -96
MCS7 19 -75

Product Tags

Use spaces to separate tags. Use single quotes (') for phrases.

Additional Information

- Summer Promo - No
Brand Mikrotik
Frequency 5 Ghz
Features (Beta) Ethernet ports, Poe in, Wireless
Applications Outdoor
