Description
DS-7608NI-E2/8P/A
NVR di tipo Embedded serie DS-7600NI-E, sino a 8 ingressi IP,switch integrato (standard AT e AF) da 8 ingressi PoE in modalità Plug&Play, 120W max erogabili. Risoluzione dei canali IP sino a 5Mpixel, banda totale massima in ingresso 50Mbps. Integrazione e configurazione delle Funzioni smart generate e supportate dalle telecamere IP Hikvision e a seconda del modello di telecamera integrata: Face Detection, Line Crossing Detection, Intrusion Detection, Audio Detection, Defocus Detection, Scene Changed detection, utili per operazioni di ricerca avanzata delle registrazioni, notifica al sw client di centralizzazione, attivazione uscite relè, invio email, attivazione della registrazione. Supporta 1 ingresso audio, canale voice talk, 1 uscita audio. Uscite video HDMI (FullHD) e VGA (FullHD), 4 ingressi allarme, 1 uscita relè. Scheda di rete Ethernet 1Gbps, sino a 128 stream in rete (80Mbps), web server multibrowser, sino a 2HDD SATA da 4TB cadauno, 2 porte USB, 1U rack mount, alimentatore interno 110-240Vac, consumo 10W, temperatura di esercizio da -10°C a 55°C. Dimensioni: 315×230×45mm
| Video/Audio Input | ||
|---|---|---|
| IP video input: | | | 8-ch |
| Two-way audio input: | | | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network | ||
| Incoming bandwidth: | | | 80Mbps |
| Outgoing bandwidth: | | | 80Mbps |
| Remote connection: | | | 128 |
| Video/Audio Output | ||
| HDMI/VGA output: | | | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Recording Resolution: | | | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate: | | | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output: | | | 1-ch, RCA (Linear, 1kΩ) |
| Decoding | ||
| Live view / Playback: | | | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: | | | 8-ch@720P, 6-ch@1080P |
| Hard Disk | ||
| SATA: | | | 2 SATA interfaces for 2 HDDs |
| Capacity: | | | Up to 4TB for each disk |
| External Interface | ||
| Network Interface: | | | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| USB Interface: | | | 1 × USB 2.0 and 1 × USB 3.0 |
| Alarm In: | | | 4-ch |
| Alarm Out: | | | 1-ch |
| POE | ||
| Interface: | | | 8 independent 100 Mbps PoE network interfaces |
| Max. Power: | | | 120W |
| Supported Standard: | | | AF and AT |
| General | ||
| Power Supply: | | | A100~240V |
| Consumption(without hard disk and POE): | | | ≤ 10W |
| Working Temperature: | | | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: | | | 10 % ~ 90 % |
| Chassis: | | | 19-inch rack-mounted 1U chassis |
| Dimensions: | | | 445 × 290 × 45mm (17.5″×11.4″×1.8″) |
| Weight(without HDD): | | | ≤ 1 kg |
Datasheet of DS-7604/7608/7616NI-E1/4P(-E2/8P 16P)/A
