Outdoor Ethernet cable SFTP cat.5e 250mt

Sku:9010352201250

Double PVC jacket Ethernet cable Cat.5e SFTP for Outdoor
336,00 €

Availability: In stock

Datasheet



Applications

High data rates, High bandwidth digital applications with low BER,

Indoor/Outdoor use, fixed installations, Low temperature

Indoor/Outdoor applications



General Construction

4 twisted pairs , cabled together overall shielded with a polyesteraluminum

foil and a tin-coated braid, and jacketed with two FRPVC

compound jackets, suitable for indoor/outdoor applications

Outer Jacket Material: UV resistant FR-PVC

Outer Diameter: 8.7 mm nom.

Weight: 90 kg/km



Design & Materials

Detailed Construction:

Outer jacket compound: UV resistant FR-PVC.

Inner jacket: FR-PVC compound, OD 6.3 mm, suitable for RJ45 connecting hardware.

Conductor Material: Annealed Bare Copper

Conductor Size: 24 AWG

Conductor Size: 0.51 mm

Conductor Construction: Solid

Insulation Material: Solid PO

Insulation O.D.: 1.07 mm nom.

Conductor unit identification: Solid/stripe

Color Code: Per TIA/EIA 568-B

Conductor unit lay-up: Pairs

Overall Shield Design: Aluminum Foil + Braid

Overall Shield Material: Aluminum/Polyester Foil

Overall Foil Shield: Yes

Overall Braid Shield: Yes

Overall Braid Material: Annealed Tinned Copper

Braid Coverage: 60 % nom.

Inner Jacket Material: FR-PVC

Inner Jacket Diameter nom.: 6.3 mm nom

Inner Jacket Color: Gray

Total number of conductors: 8

Outer Jacket Color: Black

Marking: Per request, Teldor Standard

Standards

Applicable Standards: IEC 61156, RoHS-2 2011/65/EU

Flammability Rating: IEC 60332-1, IEC 60332-3 , UL 1581 VW-1, UL CMG, CSA C22.2 FT-1



Electrical Properties:



Performance

Frequency Range: 1 - 250 MHz

Impedance: 100 Ω

Coupling Attenuation: Type I

Max. DC Resistance : 94 Ω/km@20°C

Max. Resistance Unbalance: 2 %

Capacitance Unbalance: 1.2 pF/m max.

Velocity of Propagation: 68 % nom.

Propagation Delay Skew: 35 ns/100m max.

Dielectric Strength: 700 V/minute

Dielectric Strength to Shield: 700 V/minute

Min. Insulation Resistance : 5 GΩ•km

Tensile Strength - Short Term: 130 N max.

Min. Bend Radius: 45 mm

Max. Operating Temperature: +70 °C

Min. Operating Temperature: -35 °C
