TW-IDU-NODE - UPS twidunode PoE

Sku:9010417520485

Able to manage multiple energy sources and to protect your devices. Second edition introduce the capacity of control and collect datas by remote using web interface. UPS version, have an internal battery.

115,20 €

Availability: In stock

Qty

TW-IDU-NODE UPS

HOW IT WORKS

Thanks to smart Gigabit PoE supply every standard load such as PoE+, 802.3af & 802.2at devices, IP-Cameras, IP-Phones, PBXs, Access Point, Switches, CPEs, Routers, providing Output Voltage in case of black out. Output supply is selectable in continous way between 24V up to 52V.

IMAGE OF AN IDU NODE UPS IN CHARGING

Ideal for using during installation it allow to connect and power your PoE device for a quick setup. The integrated 3100 Li Ion battery can be easily recharged with DC input.

Integrated strong Lightning Protection from overvoltage and shocks. Software overcurrent protection when overloaded and/or output shortcircuit occur. Lightning protection 25KA (8/20us) differential mode. Polarity reversal protection. Overvoltage protection up to 43Vdc.

Device perfomance and all is linked on CAN Bus can be controlled in remote way by the OS Node operating system. The management can be realized with PC, Tablet and smartphone. In clustered environment sharing and recharging one battery with more PoE, no SPOF technology (Single Point Of Failure)
